Forklift Mast Profiles

Hot-rolled special profiles for the material handling industry

Your benefits with VOL-Stahl:

High quality of the profile surface improves the look of the mast and the whole forklift truck
Straightness 0,8mm/m as standard, much tighter tolerances upon request, allows to automatize
further processing as machining, notching and welding
Twist max. 1°/m, tighter tolerances upon request
Difference on web; f = max. 1mm
Difference on flange; k = max. 1°
Profiles can be cut to fixed length, so that this step can be outsourced and thus the operating costs reduced

Length:	11.800 + 100 mm
Bundle:	weight up to 2 – 4 t
Finishing:	Anti-corrosion protection and shot blasting possible
Steel:	Q440m equiv. to S450J2 mod.

We will advise you without obligation and send you a quote.
